Kingsman IDV34 34" Direct Vent Gas Fireplace Insert

IDV34 Overview

The Kingsman IDV34 is a 34" direct vent gas insert sized for larger existing wood-burning fireplaces. Standard equipment includes a dual burner with glowing embers, ceramic glass, SIT valve, on/off rocker switch, and heat-activated variable-speed blower. The Black Clean View finishing kit (I34CV1BL) and LOGF35 5-piece fiber split oak log set are included in the listed price.

At 31,000 BTU on natural gas (28,500 BTU on propane), the IDV34 delivers up to 65% FE on propane in IPI configuration. Minimum existing fireplace opening for the standard CV1 finish is 28 5/8" W x 21 1/2" H x 17 3/4" D (CV1) / 26 1/4" W x 21 1/2" H x 15 3/4" D (CV6). Three ignition tiers are available: SIT millivolt, Proflame 1 IPI, and Proflame 2 IPI which includes built-in remote thermostat, modulation, and fan control. Optional ZCV34 RSP10 Glass Tray with bronze ember glass is sold separately for buyers who prefer a contemporary glass-bed presentation over the included log set.

Key Features

• 34" direct vent gas fireplace insert
• BTU input: 31,000 NG (max) / 28,500 LP (max)
• Efficiency NG: 62.86% (Millivolt) / 64.73% (IPI)
• Efficiency LP: 63.63% (Millivolt) / 65.63% (IPI)
• Viewing area: 25 5/8" W x 14 1/8" H
• Venting: 3"/3" coaxial flex (Kingsman flex/termination only) or MG Duravent (kit 46DVA-CL33)
• Dual burner with glowing embers and decorative ash bed
• Ceramic heat-radiating glass
• Heat-activated variable-speed blower included as standard
• On/off rocker switch
• Both Millivolt and IPI ignition operate during a power failure
• Required Black Clean View finishing kit and log set INCLUDED in base price
• Mobile home, bedroom, and bed-sitting room approved
• Optional Surround for additional installation coverage
• Optional refractory brick or porcelain reflective liner
• Optional Proflame 2 IPI tier includes remote thermostat, modulation, and fan control
• Optional RSP10 Glass Tray with bronze ember glass available separately

Specifications

Warranty

Kingsman Limited Lifetime Warranty. The heat exchanger, combustion chamber, and burner are warranted against defects in materials or workmanship for as long as the unit is owned by the original purchaser at the original installation site. Coverage applies only when the unit is installed inside the continental United States, Alaska, Hawaii, or Canada, in accordance with the printed installation instructions and applicable building codes.

During the first year after installation, Kingsman provides replacement parts and labor for any component found defective in materials or workmanship, with prior approval and through an authorized Kingsman dealer. Accent light bulbs, gasketing, and paint are excluded from the one-year coverage. Beyond year one, the Limited Lifetime coverage is parts only; labor, freight, and handling are not covered.

The warranty does not cover damage from accident, abuse, negligence, misuse, riot, fire, flood, Acts of God, corrosive atmospheres (chlorine, fluorine, etc.), unauthorized alteration or repair, improper installation or component matching, or failure to perform proper maintenance. The warranty is non-transferable and applies only to the original purchaser at the original installation site.

Downloads

• IDV34 Brochure
• IDV34 Installation Manual
