Grand Canyon LDB24L 24" Bedrock Contemporary Linear Drop-In Vented Gas Burner

LDB24L Overview

The Grand Canyon LDB24L is the smallest size in the Bedrock Contemporary Linear Drop-in family. At 24 inches it fits compact contemporary fireplace openings and trough-style masonry conversions where space is limited. Despite its size it ships with the same SIT Proflame II controls and addressable RGB LED ember lighting as the larger units, so the feature set is identical to a 96-inch installation.

The Bedrock Contemporary is purpose-built for modern interiors. The drop-in design fits trough-style masonry fireplaces and contemporary-designed wood-burning fireboxes with a 15 inch minimum depth requirement. The LDB24L ships with the case, burner, SIT Proflame II controls and handheld remote, addressable RGB LED ember lighting with IR remote and WiFi app, rating plate, install manual, flex line, and fittings. Lava rock or 1/2 inch reflective fire glass is required (selectable above or sold separately). Decorative cannonballs or linear Western Driftwood logs are optional and selectable above. Fireplace Insider ships the LDB24L nationwide. Installation must be performed by a licensed gas fitter into a fireplace approved for solid-fuel burning, with a working flue.

Key Features

• 24-inch contemporary linear drop-in burner
• Natural Gas: 30,000 BTU/hr maximum, 20,000 BTU/hr minimum
• Liquid Propane: 30,000 BTU/hr maximum, 15,000 BTU/hr minimum
• SIT Proflame II valve and IPI ignition with handheld remote, 5 flame intensity levels
• Addressable RGB ember lighting (WS2811 5V LED) with IR remote and customizable WiFi app
• 120V AC primary, 4xAA battery backup
• Vented configuration, designed for trough-style masonry or contemporary fireboxes
• Approved for indoor use and outdoor covered patio installations
• Minimum firebox: 24 inch width x 15 inch depth x 20 inch height
• Includes case, burner, SIT Proflame II controls with remote, RGB LED system with remote and WiFi app, rating plate, install manual, flex line, fittings
• Made in the USA by Grand Canyon Gas Logs (Phoenix, AZ)
• Lava rock or fire glass required (selectable above)
• Optional: Cannonballs (3 sizes, 3 colors) or Linear Western Driftwood logs

Specifications

Warranty

The Bedrock Series carries a multi-component warranty issued by Grand Canyon Gas Logs to the original purchaser:

• Burner: Lifetime warranty against manufacturer defects when installed indoors by a professional installer; one-year warranty if installed outdoors. Black paint color, sheen, and discoloration from use are not covered.
• Ceramic refractory logs (sold separately): Lifetime warranty when installed indoors; two to five-year warranty when installed outdoors depending on log type. Color fading from normal use is not covered.
• SIT Proflame II valve, pilot assembly, electronic ignition, and LED system: Two-year warranty against defects from date of purchase when installed indoors; one-year when installed outdoors. Batteries are not covered. Warranty applies only when used with Grand Canyon Gas Logs burners and logs.

All warranties are limited to the original purchaser and require documentation of purchase or installation date. Coverage does not include breakage from excessive handling once installed and fired, improper installation, or weather damage on indoor-rated components. Prior to submitting a warranty claim, the Grand Canyon Gas Logs Technical Service Department must be contacted to diagnose and validate the faulty or defective part. An approved warranty claim qualifies for a $65 labor credit (single occurrence, single trip) applied to the dealer/distributor account.

Downloads

• LDB24L Specification Sheet (PDF)
• Bedrock Burner Installation and Operation Manual (PDF)
• Bedrock Series Brochure (PDF)
• Grand Canyon Gas Logs 2026 Price Guide (PDF)
